מפרט :
Capacity- 2000VA / 1400W
Input-
Voltage- 110/120 VAC or 220/230/240 VAC
Voltage Range- 81-145 VAC / 162-290 VAC
Frequency Range- 60/50Hz(auto sensing)
Output-
AC Voltage Regulation (Batt. Mode –±5%
Frequency Range (Batt. Mode) – 50 Hz or 60 Hz ± 1 Hz
Transfer Time – Typical 2-6 ms
Spike protection – 600 Jouls
Wave Form (Batt. Mode) – Pure Sine wave
Battery
Typical Recharge time- 6 hours recover to 90% capacity
Indicators
LCD Display – AC Mode, Battery mode, Load level, Battery level, Input voltage, Output voltage, Overload, Fault & low battery
Protection
Full Protection –Over load, discharge, and overcharge protection
Alarm
Battery mode – Sounding every 10 seconds
Low Battery – Sounding every second
Overload – Sounding every 0.5 second
Battery Replacement Alarm – Sounding every 2 seconds
Fault – Continuously sounding
Physical
Dimensions DxWxH (mm) – 397 x 146 x 205
Net Weigh (kgs) – 12.25
Environment
Operating Humidity – 0-90 % RH @ 0-40 ºC (non – condensing)
Noise Level – Less than 55dB
Management
Smart RS-232/USB – Supports Windows 2000/2003/XP/Vista/2008/7/8/10 Linux, Unix, and MAC according software list
Standart – CE, EN62040-2, EN61000-4(2-5), EN61000-2-2
